T&M Amps
MPA Series
Not all amplifiers are created equal, so how can you be certain that an amplifier will work for your needs? You deserve to be confident that the amplifiers used with your test-and measurement lab benches will meet the requirements of your specific applications, are reliable, and are equally well-supported pre-and post-sale. When it comes to application expertise, reliability and support, there is no company that does it better than Maury.




Key Features
Models
Videos
Specifications
Frequency Range
Psat
Small Signal Gain
Gain Adjustment
Harmonic Power
400 MHz to 98 GHz
1 to 1,000 W
26 to 70 dB
15 to 20 dB
-15 dBc or better
Features & Benefits
- State-of-the-art solid-state GaN PAs
- Broadband design
- Variable gain adjustment
- Integrated protection circuitry
- High-resolution display
- Remote control
Filters
Name | Connector 1 | Connector 2 | Frequency Range (GHz) | Gain Adjustment (dB) | Gain Flatness (+/- dB) | Gender 1 | Gender 2 | Output Power (Typical, W) | Second Harmonic Power (dBc) | Small-Signal Gain (dB) |
---|---|---|---|---|---|---|---|---|---|---|
MPA-0G4-12G-100 | Type N | Type N | 0.4 to 12 | 20 | 4 | Female | Female | 100 | -20 | 52 |
MPA-0G6-6G-100 | Type N | Type N | 0.6 to 6 | 20 | 4 | Female | Female | 100 | -15 | - |
MPA-0G6-6G-20 | SMA | SMA | 0.6 to 6 | 20 | 4 | Female | Female | 20 | -15 | - |
MPA-0G6-6G-200 | Type N | Type N | 0.6 to 6 | 20 | 4 | Female | Female | 200 | -15 | - |
MPA-0G6-6G-500 | Type N | 7/16 | 0.6 to 6 | 20 | 4 | Female | Female | 500 | -15 | - |
MPA-0G6-6G-60 | Type N | Type N | 0.6 to 6 | 20 | 4 | Female | Female | 60 | -15 | - |
MPA-18G-26G5-10 | 3.5mm | 3.5mm | 18 to 26.5 | 15 | 3 | Female | Female | 10 | -15 | - |
MPA-18G-26G5-100 | 2.92mm | WR42 | 18 to 26.5 | 15 | 5 | Female | - | 100 | -15 | - |
MPA-18G-26G5-25 | 3.5mm | WR42 | 18 to 26.5 | 15 | 4 | Female | - | 25 | -15 | - |
MPA-18G-26G5-50 | 2.92mm | WR42 | 18 to 26.5 | 15 | 5 | Female | - | 50 | -15 | - |
MPA-18G-40G-10 | 2.92mm | 2.92mm | 18 to 40 | 15 | 5 | Female | Female | 10 | -15 | - |
MPA-18G-40G-20 | 2.92mm | WRD180C24 | 18 to 40 | 15 | 5 | Female | - | 20 | -15 | - |
MPA-18G-40G-40 | 2.92mm | WRD180C24 | 18 to 40 | 15 | 5 | Female | - | 40 | -15 | - |
MPA-26G5-40G-10 | 2.92mm | 2.92mm | 26.5 to 40 | 15 | 5 | Female | Female | 10 | -15 | - |
MPA-26G5-40G-100 | 2.92mm | WR28 | 26.5 to 40 | 15 | 5 | Female | Female | 10 | - | 50 |
MPA-26G5-40G-25 | 2.92mm | WR28 | 26.5 to 40 | 15 | 5 | Female | - | 25 | -15 | - |
MPA-26G5-40G-5 | 2.92mm | 2.92mm | 26.5 to 40 | 15 | 5 | Female | Female | 5 | -15 | - |
MPA-26G5-40G-50 | 2.92mm | WR28 | 26.5 to 40 | 15 | 5 | Female | - | 50 | - | 43 |
MPA-2G-18G-20 | SMA | SMA | 2 to 18 | 20 | 4 | Female | Female | 20 | -15 | - |
MPA-2G-18G-30 | SMA | SMA | 2 to 18 | 20 | 4 | Female | Female | 30 | -15 | - |
MPA-2G-18G-50 | Type N | Type N | 2 to 18 | 20 | 4 | Female | Female | 50 | -15 | - |
MPA-2G-26G5-2 | 3.5mm | 3.5mm | 2 to 26.5 | 15 | 4 | Female | Female | 2 | -15 | - |
MPA-2G-6G-100 | Type N | Type N | 2 to 6 | 20 | 2.5 | Female | Female | 100 | -15 | - |
MPA-2G-6G-200 | Type N | Type N | 2 to 6 | 20 | 2.5 | Female | Female | 200 | -15 | - |
MPA-2G-6G-300 | Type N | Type N | 2 to 6 | 20 | 2.5 | Female | Female | 300 | -15 | - |
MPA-2G-6G-600 | Type N | TNC | 2 to 6 | 20 | 2.5 | Female | Female | 600 | -15 | - |
MPA-2G-8G-100 | Type N | Type N | 2 to 8 | 20 | 3 | Female | Female | 100 | -15 | - |
MPA-2G-8G-1K | Type N | 7/16 | 2 to 8 | 20 | 4 | Female | Female | 1000 | -20 | 70 |
MPA-2G-8G-50 | Type N | Type N | 2 to 8 | 20 | 3 | Female | Female | 50 | -15 | - |
MPA-37G-43G-5 | 2.4mm | 2.4mm | 37 to 43 | 15 | 4 | Female | Female | 5 | - | 33 |
MPA-40G-67G-1 | 1.85mm | 1.85mm | 40 to 67 | 15 | 8 | Female | Female | 1 | - | 26 |
MPA-50G-67G-5 | WR15 | WR15 | 50 to 67 | 15 | 5 | - | - | 5 | - | 33 |
MPA-6G-18G-10 | SMA | SMA | 6 to 18 | 20 | 3 | Female | Female | 10 | -15 | - |
MPA-6G-18G-100 | Type N | Type N | 6 to 18 | 20 | 4 | Female | Female | 100 | -15 | - |
MPA-6G-18G-250 | Type N | WRD650 | 6 to 18 | 20 | 4 | Female | - | 250 | -15 | - |
MPA-6G-18G-30 | SMA | SMA | 6 to 18 | 20 | 3 | Female | Female | 30 | -15 | - |
MPA-6G-18G-50 | Type N | Type N | 6 to 18 | 20 | 3 | Female | Female | 50 | -15 | - |
MPA-8G-12G-100 | Type N | Type N | 8 to 12 | 20 | 3 | Female | Female | 100 | -35 | - |
MPA-92G-98G-30 | WR10 | WR10 | 92 to 98 | 15 | 3 | - | - | 20 | - | 50 |
No products match your current filters.
