Phase Noise Analyzers
HA7162D Series
The HA7162D Real Time Phase Noise Analyzer delivers proven accuracy, high reliability, automation and flexibility. The real time engine covers the full measurement bandwidth with extremely fast measurement speeds to reduce product development time and optimizes ATE manufacturing throughput.
- Measured noise floors
- Unparalleled analog performance
- Repeatable data
Key Features
Models
Specifications
DUT Input
Measurement Bandwidth
10MHz-26GHz (optional to 40GHz)
0.1Hz to 100MHz offsets
Features & Benefits
Automated Absolute and Additive (Residual) Measurements
Real Time Cross Correlation
Only analyzer available that allows actual noise floor measurement
