Phase Shifters
HX5100 Series
The HX5100 Series Electronic Phase Shifters are sold individually but are designed to be used in pairs with the Maury HA7000 Series Phase Noise Analyzers. These phase shifters are frequency specific and allow for full automation of additive/residual phase noise measurements with the Maury test systems while maintaining the ANSI z540 calibration.
Key Features
Models
Specifications
Input Power Range
Phase Noise (Additive)
25 dBm
-175 dBc/Hz
Features & Benefits
- Allow for full automation of additive/residual phase noise measurements
- Available in a compact and shielded housing (based on frequency)
